NF0410-HB-24V
NF0410-HB-24V - Image 2
NF0410-HB-24V - Image 3
NF0410-HB-24V - Image 4
NF0410-HB-24V - Image 5

NF0410-HB-24V

Warranty

3 years
CRI

>90
Cut points

41.7mm
Run Length (max)

5 Metres
LED Width

4mm
Watts per Metre

10w/m
IP Rating

IP65
Available Colours

6000k, 4000k, 3000k
Length

5 Metres
LED Type

White
Mounting Type

Fixings
Voltage

24V
Beam Angle

120-130
Bend Direction

Horizontal
Product Height

10mm
SKU: IN-NF041 Category: Tag:

Description

The NF0410-HB-24V is a micro-profile, horizontal-bend LED Neon Flex designed to create a smooth, dot-free line of light in compact installations. Its slim 4mm x 10mm rectangular profile bends sideways along its length, making it suitable for detailed joinery, shelving, signage and architectural lighting.

Operating at 10W per metre from a 24V DC supply, it uses 144 high-quality 2835 LEDs per metre and provides a CRI above 90. The Neon Flex can be cut every 41.6mm, produces a 120° beam angle and delivers between 130lm/m and 160lm/m, depending on the selected colour temperature.

The NF0410-HB-24V can be supplied in lengths of up to 5 metres and is available in 2700K, 3000K, 4000K and 6000K. It is rated IP65 as standard and can achieve IP67 when supplied with correctly injection-moulded end caps and input leads. It is dimmable with a compatible LED driver and is covered by a three-year warranty.

Tech Specs

Consumption Colour Temperature Lumen Output IP Rating
10w/m 2700k 130 lm/m IP67
10w/m 3000k 140 lm/m IP67
10w/m 4000k 150 lm/m IP67
10w/m 6000k 160 lm/m IP67



Product Data Sheet

PDF Download
