| Product Height | 12mm |
|---|---|
| Internal Width | 12mm |
| Available Body Colours | Anodised |
| Available Diffuser | Click |
| Available Diffuser Colours | Black, Opal, Transparent |
| Available Lengths | 4m, 3m, 2m, 1m |
| Application | Tile In |
| Product Width | 34mm |
The UNI-TILE12 C is a tile-in aluminium LED profile for integrating a clean linear light detail into tiled walls and surfaces. Its approximately 34mm overall width provides a 12mm internal channel for common LED tape formats.
A C click-fit diffuser is available in black, opal and transparent finishes. The profile is compatible with 12V and 24V LED strip systems and is supplied in an anodised finish for use with the appropriate tile build-up and installation method.
| Height | See data sheet |
| Width | See data sheet |
| Max. Tape Width | 12mm |
| Length | 2m |
| Material | Aluminium |
PDF Download
